Details
ADVANTAGE:
Light weight and flexible
Temperature range of -40 °C to +135 °C
Meets SAE J2064/SAE J3062/QC/T664-2019
Compatible with R32/R 410a/R 1234yf/ R134a/ R 410a/R404a refrigerants and mineral oils / PAGs
DATASHEET:
Dimension. | Inch | I.D. | 0.D. | Wall Thickness. mm | Wall Diff Max.mm | Work Pressure Max.MPa | Burst Pressure Min.MPa | Bend Rad | Weight |
8 | 5/16" | 8.2±0.3 | 15.2±0.4 | 3.5 | 0.4 | 3.5 | 18 | 55 | 146 |
10 | 13/32" | 10.2±0.3 | 17.2±0.4 | 3.5 | 0.4 | 3.5 | 18 | 65 | 178 |
13 | 1/2" | 13±0.3 | 19.4±0.4 | 3.2 | 0.4 | 3.5 | 18 | 75 | 202 |
15.5 | 5/8" | 15.2±0.4 | 22.8±0.5 | 3.8 | 0.4 | 3.5 | 16 | 85 | 257 |
